SELECTED MODEL:RSJ-15/190RDN7-L2
| Model | MHS-SVC50(P2)-RN7L-B | MHS-SVC60(P2)-RN7L-B | MHS-SVC70(P2)-RN7L-B | |
| Heating Capacity(A7W35) | KW | 50 | 60 | 70 |
| Heating COP(A7W35) | / | 4.70 | 4.30 | 4.00 |
| SCOP/Efficiency Rating(Average-35℃) | / | 4.70/A+++ | 4.60/A+++ | 4.50/A+++ |
| Cooling Capacity(A35W7) | KW | 50 | 60 | 65 |
| Cooling EER(A35W7) | / | 3.30 | 3.00 | 2.80 |
| Cooling ambient temperature | ℃ | -15-48 | ||
| Heating ambient temperature | ℃ | -25-43 | ||
| DHW ambient temperature | ℃ | -25-43 | ||
| Cooling supply water temperature | ℃ | -5-25* | ||
| Heating supply water temperature | ℃ | 25-85 | ||
| DHW supply water temperature | ℃ | 20-80 | ||
| sound power level(ErP-Low temperature) | dB(A) | 80 | 84.4 | 86.4 |
| Net Dimensions(W*D*H) | mm | 2000*960*1880 | ||
| Floor space | m² | 1.92 | ||
| Net weight | kg | 560 | ||
Storage size (L) 170
Running ambient temp – HP only (°C) -7 ~ 43
Running ambient temp – HP & E-Heater (°C) -20 ~ 47
Out water Temp. (°C)
Default 60°C, 55°C~70°
Dimension (DxH) (mm)
552 x 552 x 1692
Net/gross weight (kg) 95.5 / 119
Sound pressure level (dB(A)) 47
Refrigerant type/quantity (kg)
R290 / 0.29
Power supply (Ph / V / Hz)
1 / 220~240 / 50
Capacity – HP Only (kW) 1.8
COP (kW/kW) 4.2
Max. current (A) 8.5
Air flow (L/S) 150
Water inlet pipe (mm) DN20
Water outlet pipe (mm) DN20
Drainage pipe (mm) DN20
PT valve joint (mm) DN15
Max. pressure (kPa) 850
SELECTED MODEL:RSJ-15/190RDN7-L2
| Model | MHS-SVC50(P2)-RN7L-B | MHS-SVC60(P2)-RN7L-B | MHS-SVC70(P2)-RN7L-B | |
| Heating Capacity(A7W35) | KW | 50 | 60 | 70 |
| Heating COP(A7W35) | / | 4.70 | 4.30 | 4.00 |
| SCOP/Efficiency Rating(Average-35℃) | / | 4.70/A+++ | 4.60/A+++ | 4.50/A+++ |
| Cooling Capacity(A35W7) | KW | 50 | 60 | 65 |
| Cooling EER(A35W7) | / | 3.30 | 3.00 | 2.80 |
| Cooling ambient temperature | ℃ | -15-48 | ||
| Heating ambient temperature | ℃ | -25-43 | ||
| DHW ambient temperature | ℃ | -25-43 | ||
| Cooling supply water temperature | ℃ | -5-25* | ||
| Heating supply water temperature | ℃ | 25-85 | ||
| DHW supply water temperature | ℃ | 20-80 | ||
| sound power level(ErP-Low temperature) | dB(A) | 80 | 84.4 | 86.4 |
| Net Dimensions(W*D*H) | mm | 2000*960*1880 | ||
| Floor space | m² | 1.92 | ||
| Net weight | kg | 560 | ||
Storage size (L) 170
Running ambient temp – HP only (°C) -7 ~ 43
Running ambient temp – HP & E-Heater (°C) -20 ~ 47
Out water Temp. (°C)
Default 60°C, 55°C~70°
Dimension (DxH) (mm)
552 x 552 x 1692
Net/gross weight (kg) 95.5 / 119
Sound pressure level (dB(A)) 47
Refrigerant type/quantity (kg)
R290 / 0.29
Power supply (Ph / V / Hz)
1 / 220~240 / 50
Capacity – HP Only (kW) 1.8
COP (kW/kW) 4.2
Max. current (A) 8.5
Air flow (L/S) 150
Water inlet pipe (mm) DN20
Water outlet pipe (mm) DN20
Drainage pipe (mm) DN20
PT valve joint (mm) DN15
Max. pressure (kPa) 850
SELECTED MODEL:RSJ-15/190RDN7-L2
| Model | MHS-SVC50(P2)-RN7L-B | MHS-SVC60(P2)-RN7L-B | MHS-SVC70(P2)-RN7L-B | |
| Heating Capacity(A7W35) | KW | 50 | 60 | 70 |
| Heating COP(A7W35) | / | 4.70 | 4.30 | 4.00 |
| SCOP/Efficiency Rating(Average-35℃) | / | 4.70/A+++ | 4.60/A+++ | 4.50/A+++ |
| Cooling Capacity(A35W7) | KW | 50 | 60 | 65 |
| Cooling EER(A35W7) | / | 3.30 | 3.00 | 2.80 |
| Cooling ambient temperature | ℃ | -15-48 | ||
| Heating ambient temperature | ℃ | -25-43 | ||
| DHW ambient temperature | ℃ | -25-43 | ||
| Cooling supply water temperature | ℃ | -5-25* | ||
| Heating supply water temperature | ℃ | 25-85 | ||
| DHW supply water temperature | ℃ | 20-80 | ||
| sound power level(ErP-Low temperature) | dB(A) | 80 | 84.4 | 86.4 |
| Net Dimensions(W*D*H) | mm | 2000*960*1880 | ||
| Floor space | m² | 1.92 | ||
| Net weight | kg | 560 | ||
Storage size (L) 170
Running ambient temp – HP only (°C) -7 ~ 43
Running ambient temp – HP & E-Heater (°C) -20 ~ 47
Out water Temp. (°C)
Default 60°C, 55°C~70°
Dimension (DxH) (mm)
552 x 552 x 1692
Net/gross weight (kg) 95.5 / 119
Sound pressure level (dB(A)) 47
Refrigerant type/quantity (kg)
R290 / 0.29
Power supply (Ph / V / Hz)
1 / 220~240 / 50
Capacity – HP Only (kW) 1.8
COP (kW/kW) 4.2
Max. current (A) 8.5
Air flow (L/S) 150
Water inlet pipe (mm) DN20
Water outlet pipe (mm) DN20
Drainage pipe (mm) DN20
PT valve joint (mm) DN15
Max. pressure (kPa) 850
Designed and built for the most extreme conditions globally, with the operating range from -20°C to 55°C.
